Chapter 2: Pro Tools | MTRX Operation
7
Operating Buttons
Setting Pushing the Setting button scrolls trough the settings rows. The > cursor marks the selected row/function.
Up Pushing the Up button scrolls up the value/setting of the selected function.
Down Pushing the Down button scrolls down the value/setting of the selected function.
Page Pushing the Page button scrolls trough the available display pages.
Basic Display Page
(Sample Rate, Synchronization, ID, and Alarms)
Sample Rate Shows the sample rate of the MTRX. If an asterisk * is shown, the sample rate is controlled by an external digital audio
interface.
SRate Adapt Shows which external digital audio interface controls the sample rate, or it shows Intern for internal sample rate control.
Sync Source Shows the external synchronization clock source, or shows Intern when the MTRX is using the internal clock.
Unit ID/Name Shows the unit ID number and unit name. This is configured using DADman software.
Alarm/Status Shows the alarm status indicating Clock Sync or an operational error.
Alarm/Status Display Description
Sync OK Clock sync is OK.
SyncErr Clock sync failure.
TempErr The temperature inside MTRX is above 60ºC/140ºF. Check that the MTRX is properly
installed to allow airflow.
Fan Err One of the two fans is not working correctly. Contact an Avid representative.
CardErr Fault in one of the A/D or D/A cards. Contact an Avid representative.
Psu Err Power supply failure. Contact an Avid representative.
Setting
Up
Down
Page
Pro Tools | MTRX
PT HD1
Sample Rate
*
>
:
SRate Adapt
Sync Source
1:NameUnit
48
Intern
Sync OK
