Appendix A: Specifications 28
Digital I/O and Synchronization
Network Interface
Electrical Specifications
Power supply cord must be min. light sheathed flexible cord according to IEC60227 (designation 60227 IEC 52) and include a protec-
tive earth conductor having a green-and-yellow insulation. Cross-sectional
areas min. 3 x 0.75mm.
Digital I/O formats
Supported sample rate
AES/EBU, Pro Tools DigiLink Mini, Dante IP Audio/up to
192 kHz, MADI/up to 384 kHz and DSD
Synchronization/sample rate AES11, Word Clock, All digital inputs, Video Sync (word
clock connector) / PAL, NTSC, SECAM
DSD sample rates 8224 & 5.6448 Mhz (64 & 128 fs)
Dynamic range (A) > 128 dB
THD+N(A) < –110 dB @ –3dB FS / 0.00031%
Cross talk < 120 dB
Max output level Adjustable from –60 dBu to 24 dBu in steps of 0.1 dB
Interface 1000BASE-T, RJ45 connector, 4-pair connection
Power consumption 90 VA maximum
Input voltage 90–260 VAC
100–240 VAC Nominal, 47–63 Hz
Mains fuse, mounted in IEC connector 1 A, T1AH/250V
Mains line plug type Correct type acc. to standard
110–125V UL817 and CSA C22.2 no 42
220–230V CEE 7 page VII, SR section 107-2-D1/IEC 83 page C4
240V BS 1363 of 1984.Specification for 13A fused plugs and
switched and un-switched socket outlets
