Stage 4820
XO16 Analog/Digital Output Card
All measurements at Fs=48 kHz with 150 Ohm source impedance and 600 Ohm load impedance, unless otherwise specified.
0 dBU = 0.775Vrms.
Stage 48 Mechanical Specifications
XO16 Analog Line Outputs
Parameter Specifications Limit Units Condition/Comment
Type Balanced, XLR3-Male
Impedance 50 Ohm Each leg to ground
Maximum Output Level +24 max dBu
D/A Converter Latency 0.58 ms Fs=48kHz
XO16 Digital Outputs
Parameter Specifications Limit Units Condition/Comment
Type Balanced, XLR3-Male
Format AES3 (IEC-60958 Type I)
Impedance 110 Ohm Each leg to ground
Word Length 24 bit
Sample Rate 48 kHz
Sample Rate Conversion None
Dithering None
Channel Status Info Pro, Audio 48K, No Emphasis
Max Cable Length 100 meter Without equalization, 110 Ohm
cable
Stage 48 Specifications
Dimensions (H x W x D) 8.75 x 17.05 x 18 inches (222 x 433 x 455 mm) without ears
8.75 x 19 x 18 inches (222 x 481 x 455 mm) with ears
Rack Spaces 5U
Stage I/O Card Slots 3
Weight Empty: 30lb (13.5kg)
Full: 42.5lb (19.3kg)
Power Requirements 100–240 VAC, 50–60 Hz, 140 W
Primary and Redundant Snake Connectors RJ45 Neutrik etherCON (2)
Snake Cable Type Shielded Cat5e or better (Neutrik etherCON connectors required)
Max Snake Cable Length 100 metre (323 feet)
