Stage 4810
3 Connect the included IEC power cable(s) between the Power
connector(s) on any Stage 48 units present and your power
source.
4 Press the Power switch on the first Stage 48 to power on the
device. The Status LED indicator is lit solid yellow while the
Stage 48 initializes.
5 If applicable, for the second Stage 48 connect power and
power on the device.
6 Wait for the Stage 48(s) to initialize. Initialization is com-
plete when the Power and Status LEDs on the Stage 48 front
panel are lit solid green.
7 Power on SC48 and wait for the Ethernet Snake card to ini-
tialize, indicated by a lit green Status LED. Audio will not pass
until the SC48 is fully initialized.
8 Both the Act and Sig LEDs on Stage 48 (s) and the Ethernet
Snake card in SC48 should be lit for all connected Ethernet
snakes.
9 You should now confirm your I/O in VENUE.
Confirming I/O
After making snake connections and powering up your sys-
tem, you can confirm your system’s available Stage I/O.
To confirm I/O in your system:
1 Go to Options > Devices to view your system hardware status.
The newly installed hardware should be displayed. Stage 48
I/O appears in the SC48 I/O slots in the graphic.
2 Go to the Patchbay page and click the Stage tab to verify that
the inputs and/or outputs are available in the Patchbay.
A flashing red Power LED indicates a potential power prob-
lem. Power down, unplug Stage 48, and verify the power
source. See “Recessed Pushbutton” on page 6 for informa-
tion on LED indicator codes.
If the Sig LED does not light after you have connected a
Stage 48, make sure the ID switches on all connected
Stage 48 units are set properly.
