Motor M2 is not connected or incorrectly connected
(contact failure). Check connections.
E
The maximum operating time has been reached (a
motor is idle and the stop has not been reached?).
Check that the motor is engaged.
E
Panel M1 closed before panel M2. Increase the time
interval between the movement of both panels.
E
Three obstacles detected in a row during opening.
Check the gate movement area.
E
Three obstacles detected in a row during closing.
Check the gate movement area.
E
The main power supply has been cut during a
movement phase OR the battery is too weak for
proper operation.
E
Self-learning is not valid (it was never performed or
a setting that requires repetition of self-learning has
been changed). Start self-learning.
E
Automatic closing has been cancelled. Generated if
the gate re-opens 3 times (10 in collective mode) after
a photocell has been obstructed during automatic
closing OR if the beam was obstructed for more than
3 minutes.
E
The gate control input (2B) is permanently earthed.
Check the connections.
E
2.2 - Manual control
The panels can be manoeuvred without any prior programming, for example during motor installation.
• To enter manual mode, press OK for 3 seconds. LED L4 will flash.
• Press and hold the button for the desired movement.
F - MAINTENANCE AND UPKEEP
