B - PRODUCT DESCRIPTION
1 - KIT CONTENTS
1
x 1
4
x 1
4
x 2
4
x 2
2
x 1
3
x 2
5
x 2
6
x 2
7
x 2
8
x 2
9
x 4
10
x2
11
x 4
12
x 4
13
x 2
14
x 6
15
x 4
16
x 4
17
x 4
18
x 4
19
x6
1 Main motor with electronic card
2 Secondary motor
3 Remote control
4 Flashing light and screws
5 Rear arm
6 Front arm
7 Pillar mounting bracket
8 Gate mounting bracket
9 M12 – L40 screw
10 M8 – L25 screw
11 M10 – L90 screw
20
x 1
20
x 6
20
x 6
20
x 4
21
x 1
22
x 4
12 M8 CHC – L30 screw
13 M8 Washer
14 M8 Spring washer
15 M12 locknut
16 M10 nut
17 M10 spring washer
18 M10 washer
19 M10 - L120 fastening pin
20 Photocells and their screws
21 Override key
22 M12 washer
