2.2 - PHOTOCELL ALIGNMENT PROCEDURE
(OPTIONAL)
The electronic card of this motorised gate is on
standby after 1 minute with no action.
On standby, the photocells no longer have power.
• To prolong the “activation” time, press and release
one of the buttons.
When the photocells have power, a green indicator is
lit inside each one.
When the photocells are not aligned, a second red
indicator light turns on in the RX photocells.
When the photocells are aligned, an orange indicator
light turns on inside the RX photocell.
• Move your hand in front of it to hide the infrared
beam. The green indicator light turns on and the
orange indicator turns off. A relay click can be
heard when the status changes.
2.3 - OPERATING MODE
This automatic gate opening mechanism has 3
operating modes.
Semi-automatic mode (mode 1) (default)
• Closed gate -> to open the gate, press and release
the gate command.
• Open gate -> to close the gate, press and release
the gate command.
While the gate is in motion, you can stop it by
pressing the (gate or pedestrian) command.
By pressing on the gate command again, the gate
swings in the opposite direction.
Automatic closing mode (mode 2)
• Closed gate: pressing and releasing the gate
command once opens the gate, which remains
open for a certain time (adjustable time, see “Time
delay”), then closes automatically.
• During the time delay, you can cancel the
automatic closure by pressing the (gate or
pedestrian) command. The gate stays open and
you must press the gate command to close the
gate.
While the gate is in motion, you can stop it by
pressing the (gate or pedestrian) command.
Collective mode (mode 3)
This mode is used for a collective access gate.
• Closed gate: pressing and releasing the gate
command once opens the gate, which remains
open for a certain time (adjustable time, see “Time
delay”), then closes automatically.
Unlike the automatic closure mode:
• If you press a command during opening, it will not
be acknowledged.
• If you press a command during the time delay,
instead of cancelling the automatic closure, the
time delay starts again at 0.
• If you press a command during closure, the gate
shuts, opens again and starts the automatic
closure time delay.
• You can only control the complete gate. The
pedestrian command does not work.
To choose the operating mode, set a value
from 1 to 3. Follow the procedure below
• Press “PROG” for 3 seconds. L0 will flash once
and L1 will switch on.
• Press OK and the number of red LEDs that turn on
will indicate the operating mode that has already
been set (mode 1 by default).
• To change the operating mode, use the “–” and
“+” buttons, then confirm with the OK button. All
the LEDs turn on and off to confirm the operation.
N.B.: applicable regulations require the installation
of photocells for security during automatic closing.
2.4 - TIME DELAY
The time delay is the time during which the gate
remains open before closing automatically (if
automatic closing is activated).
To adjust this value, follow the procedure
below
• Press “PROG” for 3 seconds. L0 will flash once
and L1 will switch on.
• Press “+” once. L2 will turn on instead of L1.
• Press OK, and the number of red LEDs that turn on
will indicate the set value.
• Use the “+” and “-” buttons to change this value
(see table below).
• Press OK to confirm this value. All the LEDs will turn
on and off to confirm the operation.
This time is adjustable from 15 seconds to 90
