1 - TECHNICAL CHARACTERISTICS
The technical characteristics are provided as an indication only and for a temperature of +20°C. The
company Avidsen reserves the right to modify these characteristics at any time, while under all circumstances
guaranteeing these products’ smooth operation and the type of use intended, in an aim to improve these
products.
MOTORS
Type 24VDC motors, reduction gear, type: telescopic
Power supply 24VDC
Nominal force 800N
Speed at rated torque 2cm/sec
Consumption at rated strength 3A
Cable 50cm. 2 x 0.75mm² section cables
Assigned operating duration 10 minutes
Maximum number of cycles/day 50
Operating temperature -20°C/ +60°C
Protection rating IP44
ELECTRONIC CONTROL BOX
Type Electronic control box for 2 x 24VDC motors
Contents 1 AVLO electronic card, 1 x 230 / 24VAC transformer
Power supply 230VAC / 50Hz or 24VDC
Maximum assigned power 240W
Motor output (- M1 + / - M2 +)
2 outputs for 24VDC motor
- Maximum output current at start for 3s = 10A.
- Maximum output current after start = 10A
Flashing light output (- Warn +)
Flashing controlled by the electronic card.
For flashing light with LED, 24V/10W maximum
+24VDC power output (+24V/GND) To power the photocells. 3.3W maximum
Photocell input (GND/PHO) Input for dry contact that is normally closed
Input for control device (2B / GND) “2
panels”
Input for dry contact that is normally open (closing the
contact triggers a command to set the gate in motion or
stop it)
