EN45EN 44
Antenna input (ANT/GND) 50Ohm
Remote control option for:
- The gate
- Pedestrian access
Number of remote control buttons that
can be memorised
15 with 1 gate command button and 1 pedestrian
command button
Operating temperature -20°C/+60°C
Protection rating IP44
FLASHING LIGHT
Type
LED lighting 2W max
Flashing controlled by the electronic card
Power supply Max supply voltage: 24VDC
Operating temperature -20°C/ +60°C
Protection rating IP44
REMOTE CONTROL
Type
Type: OOK AM modulation. 16-bit Rolling code encoder
(i.e. 65,536 possible combinations)
Frequency 433.92MHz
Power supply 3V, CR2032 battery
Keys 4 keys
Radiated power < 10mW
Battery life 2 years at a rate of 10 x 2s uses per day
Operating temperature -20°C/+60°C
Protection rating
IP40 (For indoor use only: home, car or sheltered
location)
G - TECHNICAL AND LEGAL INFORMATION
