Installation – Electrical connection with the magnetic vibrator
4–14 ©1998 AViTEQ Vibrationstechnik GmbH Version 02/2003
4.4.2 Line lengths
We define the line length as being the distance between vibration conveyor device
and main distributor. Smaller line cross sections or longer line lengths could result
in faults (see Chapter 7).
The maximum permissible line length is 300 m.
An appropriate line cross section is to be used for a given vibrator current.
F
The line cross sections (based on length) are given in the operating manual
for the magnetic vibrator.
The maximum allowable voltage drop between the vibration conveyor device and
main distributor must not exceed a value of 5%. The line cross sections in the
operating manual for AVITEQ magnetic vibrators are dimensioned accordingly.
When using a device (magnetic vibrator) produced by another manufacturer, you
must mathematically recheck the line resistance.
NOTE
NOTE
