Operating Manual for Controller VIBTRONIC
®
SC(E)…-2
©2002 AViTEQ Vibrationstechnik GmbH Version 02/2003 5–1
5
5 Commissioning
5.1 Commissioning with AViTEQ magnetic
vibrator
When commissioning with the original AViTEQ magnetic vibrator, you are advised
to follow the commissioning steps provided in the respective chapter of the oper-
ating manual of the magnetic vibrator.
In the event of malfunction, refer to Chapter 7 located towards the end of this
Operating Manual. Additional information can be found in the Troubleshooting
chapter of the operating manual for the AViTEQ magnetic vibrator or for the
AViTEQ vibration conveyor device.
5.2 Commissioning with vibrators from third
party manufacturers
5.2.1 Setting the vibrator nominal voltage
The vibrator nominal voltage U
VN
, which can be measured at terminals 3 and 4 of
the controller, is set at the factory to a fixed value for use with original AViTEQ
devices.
If a magnetic vibrator from another manufacturer is to be used, the setting must
be checked prior to commissioning and, if necessary, adjusted.
The vibrator nominal voltage can be set by AViTEQ Vibrationstechnik; when order-
ing the controller, provide us with the actual vibrator nominal voltage of the third
party device!
If you would like to set the vibrator mains voltage yourself, carry out the steps in
the following commissioning description.
5.2.2 Commissioning
For the commissioning, we refer you to the commissioning instructions provided
by the manufacturer of your magnetic vibrator.
NOTE
