Appendix
F-FEM-CNT — User’s Guide
6 Appendix
6.1 Technical Data
Description Data
Case 55 mm x 264 mm (6 HU) x 180 mm (width x height x depth)
Supply voltage 24 V DC +
20 %
Reverse battery protection provided
Power consumption 8 watt (typical) without external load
11 W (max)
Ambient temperature 0 to 60 °C
Storing temperature -20 to 85°C
Relative humidity for storage 0 to 90 %
Relative humidity for operation 20 to 80 %, no condensation
Operating altitude 3000 m max. above sea level
Number of channels 4 sensor sockets with 3 signal conditionings each
6 counter channels
Interfaces 3 IEEE1394 bus interfaces
2 Add-on interfaces to F-FEM-DIO
Cable lengths IIEEE1394 max. 20 m, for longer cables: repeater
Add-on max. 15 m
Weight 1.06 kg
Tab. 14

AVL F-FEM-CNT Specifications
