Starting the Function Diagnostics

Overview

With the function diagnostics you can get an overview of the functional

status of your FRITZ!Box and its internet connection, and of your home

network as well. In the case of an error the diagnostics results can

help you localize and remedy any problems.

Areas of Diagnostics

The following areas are checked:

Area Checkpoint / Status

FRITZ!Box 7530 • name of the FRITZ!Box

• FRITZ!Box Version

• FRITZ!OS up to date

Registration configured login method to the FRITZ!Box user

interface

LAN • allocation of LAN ports

• power settings on LAN ports

Wireless LAN • wireless LAN frequency band

enabled/disabled with wireless function

• number of wireless LAN devices

connected

• security settings

DECT • DECT enabled/disabled

• number of DECT devices connected

USB devices • number of storage media connected

• number of partitions

• connected printers

User Interface: Diagnostics Menu

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

181FRITZ!Box 7530
