AVM FRITZ!Box 7530 User Manual

Buttons
Button Functions
Power/ DSL WLAN Fon/ DECT Connect/ WPS Info
1 2 3
No. Button Function
1 WLAN Switch wireless LAN on and off; see page 167
2 Fon/DECT Find cordless phones (paging call)
3 Connect/WPS • Register cordless telephones with the
FRITZ!Box; see page 48
• Register wireless devices with the
FRITZ!Box via WPS; see page 47
Functions and Structure
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
25FRITZ!Box 7530

AVM FRITZ!Box 7530 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	866 Mbit/s
WLAN data transfer rate (second band)	400 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
DSL specification	DSL router with firewall / NAT, DHCP server, DynDNS client, UPnP AV
Supported network protocols	IPv6
Security algorithms	WPA2, WPS
Product type	Tabletop router
Product color	Black, Red, White
LED indicators	DSL, Power, WLAN
Power source type	DC
Power consumption (typical)	6 W
Number of products included	1 pc(s)
Cables included	DSL, LAN (RJ-45)

Weight and Dimensions

Depth	150 mm
Width	208 mm
Height	37 mm
