Using Wizards

Overview

Wizards guide you step by step through the most important FRITZ!Box

functions. All settings options are commented on in detail. Follow the

wizard’s instructions in each window to configure your settings.

“Wizards” menu

When you cancel a wizard, any entries you made during the course of

using the wizard are discarded.

Range of Functions

The following wizards assist you in step-by-step configuration:

Wizard Function

Manage Telephony

Devices

Connecting and configuring the following

devices:

• telephones

• answering machines

• fax machines

• cordless (DECT) telephones

User Interface: Wizards Menu

• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •

209FRITZ!Box 7530
