Avtech AVN80X User Manual

21
APPENDIX 1 PRODUCT SPECIFICATIONS
AVN80X
▓ Network
Network Compression H.264 / MPEG4 / MJPEG
Multiple Video Streaming
(Encode Modes, IPS, Resolution)
3 (H.264, MJPEG, MPEG4)
LAN Port YES
LAN Speed 10/100 Based-T Ethernet
Supported Protocols
DDNS, PPPoE, DHCP, NTP, SNTP, TCP/IP,
ICMP, SMTP, FTP, HTTP, RTP, RTSP, UPnP
Frame Rate NTSC:30, PAL:25
Number of Online Users 10
Security Multiple user access levels with password
Web management Internet Explorer on Windows operating system
▓ Camera
Image Sensor 1/3" Live MOS image sensor
Video Resolution SXGA, SXVGA, 720P, VGA, QVGA
Min Illumination 0.1 Lux / F1.5, 0 Lux (LED ON)
Shutter Speed 1 / 60 (1/50) to 1 / 100,000 sec.
S/N Ratio More than 48dB (AGC off)
Lens f3.8mm / F1.5
Viewing Angle 75°
White LED YES (1W, 10 meters)
White Balance ATW
AGC Auto
IRIS Mode AES
PIR Sensor Detection Range 76 wide angle with up to 6m long distance at 2m height (under 30C
)
Micro SD Card Slot YES
External Alarm I/O YES
Microphone YES
Speaker YES
Power Source (±10%) 5V / 2A
Operating Temperature -0℃~40℃
▓ Others
Mobile Surveillance iPad, iPhone & Android
Audio Detection YES
RTC (real-time clock) YES
Motion Detection YES
Digital Pan / Tilt / Zoom YES
Event Notification Push Video / FTP / Email
Minimum Web Browsing Requirements
Pentium 4 CP‧ U 1.3 GHz or higher, or equivalent AMD
256 MB RAM‧
AGP graphics card, Direct Draw, 32MB RAM‧
Windows ‧ 7, Vista & XP, DirectX 9.0 or later
Internet Explorer ‧ 7.x or later
** The specifications are subject to change without notice.
** Dimensional tolerance: ± 5mm
