Identification of Controls
8 9
Identification of Controls
Product information
Timer Recording Standby
Timer Recording Error
Recording in Progress
Timer Recording in
Progress
Recording Pause
- RECORDING MODE -
DVD playback
Fast playback
Fast reverse playback
Slow playback
Pause picture
- DVD OPERATION -
VCR playback
Fast forward
Rewinding
Fast playback (CUE)
Fast reverse playback
(REVIEW)
Slow playback
Still picture
Stop
Child Lock
- VCR OPERATION -
Operation Display Window
! Power Cord
It is a jack for supplying power to the unit.
Connect to outlet in a wall.
@ AUDIO OUTPUT Jack
# COMPONENT OUTPUT Jack
$ Digital Output (COAXIAL) Jack
To enjoy sound quality of theater level in
home, connect this jack with amp or unit
embedded with digital audio decoder.
% A/V OUTPUT Jack
^ A/V INPUT Jack
& Connection to ANTENNA Cable
* Connection to TV
Main body (Rear Panel)
!
@ # % ^ &
$ *
