AXIS 200 User’s Manual Appendix F: The RS232 Serial Port
81
Notes:
❏ The above session was performed on a US Robotics modem.
Please be aware that the required settings for other types of
modems may differ from those defined above. Axis are currently
checking the compatibility of the AXIS 200 with other popular
modem types and will release configuration details for these
shortly.
❏ Some modem manufacturers require you to set a DIP switch to
disable command echoing. e.g. USR Sportster 28k8 modems
require DIP switch 4 to be set to the DOWN position.
Ty p i c a l m od e m
settings
Typical US Robotics Sportster Vi 33600 Faxmodem settings are
defined below:
Note:
❏ The screen dump for your modem might differ from the above, as
the settings can vary between modem types.
B0 E0 F1 M0 Q0 V1 X1 Y0
BAUD=115200 PARITY=N WORDLEN=8
DIAL=PULSE ON HOOK
&A1 &B1 &C1 &D2 &H2 &I0 &K1 &M4 &N0 &R1
&S0 &T5 &U0 &Y1
S00=000 S01=000 S02=043 S03=013 S04=010
S05=008 S06=002 S07=059 S08=002 S09=006
S10=007 S11=070 S12=050 S13=000 S14=000
S15=000 S16=000 S17=000 S18=000 S19=000
S20=000 S21=010 S22=017 S23=019 S24=000
S25=005 S26=000 S27=001 S28=008 S29=020
S30=000 S31=000 S32=000 S33=000 S34=000
S35=000 S36=000 S37=000 S38=000 S39=000
S40=000 S41=000 S42=000 S43=200 S44=015
S45=000 S46=050 S47=000 S48=084 S49=000
S50=000 S51=000 S52=000 S53=000 S54=064
S55=000 S56=000 S57=000
LAST DIALED #:
OK
