Axis A1601 User Manual

AXISA1601NetworkDoorController
Specifications
FunctionPinNotes
Specications
DCground
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mAforeach
I/O
Digitalinput–Connecttopin1toactivate,orleaveoating
(unconnected)todeactivate.
0tomax30VDC Congurable
(InputorOutput)
3–6
Digitaloutput–Internallyconnectedtopin1(DCground)when
active,andoating(unconnected)wheninactive.Ifusedwithan
inductiveload,e.g.,arelay,connectadiodeinparallelwiththe
load,toprotectagainstvoltagetransients.EachI/Oiscapableof
driving12VDC,50mA(max)externalload,ifinternal12VDC
output(pin2)isused.Inthecaseofusingopendrainconnections
incombinationwithanexternalpowersupply,thentheI/Oscan
manageDCsupplyof0–30VDC,100mA.
0tomax30VDC,opendrain,
100mA
1
DCground
2
DCoutput12V
3
I/Oconguredasinput
4
I/Oconguredasoutput
5
CongurableI/O
6
CongurableI/O
Externalconnector
4-pinterminalblockforexternaldevices,forexampleglassbreakorredetectors.
UL:TheconnectorhasnotbeenevaluatedbyULforburglar/realarmuse.
FunctionPinNotes
Specications
DCground
1,3
0VDC
40

Axis A1601 Specifications

General

Operating System	Linux
Power	12-24 V DC
Protocols	IPv4, IPv6, SNMPv1/v2c/v3, UPnP
USB Ports	USB 2.0
Serial Ports	RS-485/RS-422
