AXISA1601NetworkDoorController

Systemconﬁguration

-BinLE2Hex–Binarydataisencodedashex-lowercasenumbersinlittleendianbitorder.Thehexadecimal

system,alsoknownasthebase-16numbersystem,consistsof16uniquesymbols:thenumbers0–9andthe

lettersa–f.Littleendianbitordermeansthattherstbitisthesmallest(leastsignicant).

-BinBE2Hex–Binarydataisencodedashex-lowercasenumbersinbigendianbitorder.Thehexadecimalsystem,

alsoknownasthebase-16numbersystem,consistsof16uniquesymbols:thenumbers0–9andthelettersa–f.

Bigendianbitordermeansthattherstbitisthebiggest(mostsignicant).

-BinLEIBO2Int–BinarydataisencodedinthesamewayasforBinLE2Int,butthecardrawdataisreadwith

invertedbyteorderinamultiple-bytesequencebeforeeldmapsaretakenouttobeencoded.

-BinBEIBO2Int–BinarydataisencodedlikeforBinBE2Int,butthecardrawdataisreadwithinvertedbyteorder

inamultiple-bytesequencebeforetheeldmapsaretakenouttobeencoded.

Forinformationaboutwhicheldmapsyourcardformatuses,seethemanufacturer’sinstructions.

CongureServices

TheCongureServicesintheSetuppageisusedtoaccessthesetupfortheexternalservicesthatcanbeusedwiththedoorcontroller.

SmartIntego

SmartIntegoisawirelesssolutionthatincreasesthenumberofdoorsadoorcontrollercanhandle.

PrerequisitesSmartIntego

ThefollowingprerequisitesneedstobemetbeforeproceedingwiththeSmartIntegoconguration:

•Acsv-leneedstobecreated.Thecsv-lecontainsinformationaboutwhatGatewayNodeanddoorsthatareusedinyour

SmartIntegosolution.TheleiscreatedinastandalonesoftwareprovidedbyaSimonsVosspartner.

•TheHardwareCongurationofSmartIntegohasbeendone,seeHowtocreateanewhardwarecongurationforwireless

locksonpage14.

Note

•SmartIntegoCongurationtoolmustbeversion2.1.6452.23485,build2.1.6452.23485(8/31/20171:02:50PM)orlater.

•TheAdvancedEncryptionStandard(AES)isnotsupportedforSmartIntego,andmustthereforebedisabledinthe

SmartIntegoCongurationtool.

HowToCongureSmartIntego

Note

•Makesurethatprerequisiteslistedhavebeenmet.

•Forincreasedvisibilityofthebatterystatus,gotoSetup>Congureeventandalarmslogs,andaddeitherDoor—

BatteryalarmorIdPoint—Batteryalarmasanalarm.

•ThedoormonitorsettingscomefromtheimportedCSVle.Youshouldn'tneedtochangethissettinginanormal

installation.

1.ClickBrowse...,selectthecsv-leandclickUploadle.

2.SelectaGatewayNodeandclickNext.

3.Apreviewofthenewcongurationisshown.Disablethedoormonitorsifneeded.

4.ClickCongure.

5.Anoverviewofthedoorsincludedinthecongurationisshown.ClickSettingstocongureeachdoorindividually.
