AXISA1601NetworkDoorController
Systemconfiguration
2.IfaREXdevicesuchasabutton,sensor,orpushbarwillbeused,selectthecheckboxandthenselecttheoptionthat
matcheshowtheREXdevice’scircuitswillbeconnected.
IftheREXsignaldoesnotinuencedooropening(forexamplefordoorswithmechanicalhandlesorpushbars),select
REXdoesnotunlockdoor.
3.IfconnectingmorethanonereaderorREXdevicetothedoorcontroller,dotheprevioustwostepsagainuntileach
readerorREXdevicehasthecorrectsettings.
AboutreaderandREXdeviceoptions
Thefollowingreaderoptionsareavailable:
•Wiegand–SelectforreadersthatuseWiegandprotocols.ThenselecttheLEDcontrolthatissupportedbythereader.
ReaderswithsingleLEDcontrolusuallytogglebetweenredandgreen.ReaderswithdualLEDcontrolusedifferentwires
fortheredandgreenLEDs.ThismeansthattheLEDsarecontrolledindependentlyofeachother.WhenbothLEDsareon,
thelightappearstobeamber.Seethemanufacturer’sinformationaboutwhichLEDcontrolthereadersupports.
•OSDP,RS485halfduplex–SelectforRS485readerswithhalfduplexsupport.Seethemanufacturer’sinformation
aboutwhichprotocolthereadersupports.
ThefollowingREXdeviceoptionsareavailable:
•Activelow–SelectifactivatingtheREXdeviceclosesthecircuit.
•Activehigh–SelectifactivatingtheREXdeviceopensthecircuit.
•REXdoesnotunlockdoor–SelectiftheREXsignaldoesnotinuencedooropening(forexamplefordoorswith
mechanicalhandlesorpushbars).Thedoorforcedopenalarmwillnotbetriggeredaslongastheuseropensthedoor
withintheaccesstime.DeselectifthedoorshallunlockautomaticallywhentheuseractivatestheREXdevice.
Note
Mostlock,doormonitor,andreaderoptionscanbechangedwithoutresettingandstartinganewhardwareconguration.
GotoSetup>HardwareReconguration.
Howtousesupervisedinputs
Supervisedinputsreportonthestatusoftheconnectionbetweenthedoorcontrollerandthedoormonitors.Iftheconnection
isinterrupted,aneventisactivated.
Tousesupervisedinputs:
1.Installendoflineresistorsonalltheusedsupervisedinputs.Seetheconnectiondiagramonpage38.
2.GotoSetup>HardwareRecongurationandselectEnablesupervisedinputs.Youcanalsoenablesupervisedinputs
duringthehardwareconguration.
Aboutsupervisedinputcompatibility
Thefollowingfunctionsupportssupervisedinputs:
•Doormonitor.SeeDoorconnectoronpage38.
Howtocreateanewhardwarecongurationforwirelesslocks
1.GotoSetup>HardwareCongurationandclickStartnewhardwareconguration.
2.EnteranamefortheAxisproduct.
3.Inthelistofperipherals,selectamanufacturerforawirelessgateway.
4.Ifyouwanttoconnectawireddoor,selectthe1DoorcheckboxandclickNext.Ifnodoorisincluded,clickFinish.
14

Axis A1601 Specifications

General

Operating System	Linux
Power	12-24 V DC
Protocols	IPv4, IPv6, SNMPv1/v2c/v3, UPnP
USB Ports	USB 2.0
Serial Ports	RS-485/RS-422
