Axis A1601 - Peripheral Setup and Verification

AXISA1601NetworkDoorController
Systemconfiguration
Howtoaddandsetupnetworkperipherals
Important
•BeforeyousetupthenetworkperiphalsyouneedtoaddauserinAXISA9188NetworkI/ORelayModule.GototheAXIS
A9188webinterface>Preferences>Additionaldeviceconguration>Basicsetup>Users>Add>Usersetup.
•Don’taddanotherAXISA1001NetworkDoorControllerasanetworkperipheral.
1.GotoSetup>NetworkPeriphalstoaddadevice
2.Findyourdevice(s)underDiscovereddevices.
3.ClickAddthisdevice
4.Enteranameforthedevice
5.EntertheAXISA9188usernameandpassword
6.ClickAdd.
Note
YoucanmanuallyaddnetworkperiphalsbyenteringMACaddressorIPaddressintheManuallyadddevicedialog.
Important
Ifyouwanttodeleteaschedule,rstmakesureit’snotusedbythenetworkI/Orelaymodule.
HowtosetupI/Osandrelaysinnetworkperipherals
Important
BeforesettingupthenetworkperipheralsyouneedtoaddauserinAXISA9188NetworkI/ORelayModule.GototheAXIS
A9188webinterface>Preferences>Additionaldeviceconguration>Basicsetup>Users>Add>Usersetup.
1.GotoSetup>NetworkPeriphalsandclickontheAddeddevicesrow.
2.ChoosewhichI/Osandrelaystosetasoor.
3.ClickSetasoorandenteraname.
4.ClickAdd.
Note
InAXISEntryManageryoucanaddmaximum16oors.
VerifytheHardwareConnections
Whenthehardwareinstallationandcongurationiscomplete,andanytimeduringthedoorcontroller’slifetime,youcanverifythe
functionoftheconnecteddoormonitors,NetworkI/ORelayModules,locksandreaders.
Toverifythecongurationandaccessthevericationcontrols,gotoSetup>HardwareConnectionVerication.
VericationControlsDoors
•Doorstate–Verifythecurrentstateofthedoormonitor,dooralarmsandlocks.ClickGetcurrentstate.
•Lock–Manuallytriggerthelock.Bothprimarylocksandsecondarylocksifthereareanywillbeaffected.ClickLockor
Unlock.
•Lock–Manuallytriggerthelocktograntaccess.Onlyprimarylockswillbeaffected.ClickAccess.
