AXISA1601NetworkDoorController

Systemconﬁguration

5.Dependingonwhatlockmanufactureryougot,proceedaccordingtooneofthebullets:

-ASSAAperio:ClickthelinktoviewthehardwarepinchartorclickCloseandgotoSetup>Hardware

Recongurationtocompletetheconguration,seeAddAssaAperio

doorsanddevicesonpage15

-SmartIntego:ClickthelinktoviewthehardwarepinchartorclickClickheretoselectwirelessgatewayand

conguredoorstocompletetheconguration,seeHowToCongureSmartIntegoonpage19.

AddAssaAperio

doorsanddevices

BeforeaddingawirelessdoortothesystemitneedstobepairedwiththeconnectedAssaAperiocommunicationhub,using

AperioPAP(Aperioprogrammingapplicationtool).

Toaddawirelessdoor:

1.GotoSetup>HardwareReconguration.

2.UnderWirelessDoorsandDevicesclickAdddoor.

3.IntheDoornameeld:Enteradescriptivename.

4.IntheIDeldunderLock:Enterthesix-character-longaddressofthedevicethatyouwanttoadd.Thedeviceaddressis

printedontheproductlabel.

5.Optionally,underDoorpositionsensor:ChooseBuiltindoorpositionsensororExternaldoorpositionsensor.

Note

Ifusinganexternaldoorpositionsensor(DPS),makesurethattheAperiolockdevicehassupportfordoorhandlestate

detectionbeforeconguringit.

6.Optionally,intheIDeldunderDoorpositionsensor:Enterthesix-character-longaddressofthedevicethatyouwantto

add.Thedeviceaddressisprintedontheproductlabel.

7.ClickAdd.

Howtocreateanewhardwarecongurationwithelevatorcontrol(AXISA9188)

Important

BeforecreatingaHWcongurationyouneedtoaddauserinAXISA9188NetworkI/ORelayModule.GototheA9188web

interface>Preferences>Additionaldeviceconguration>Basicsetup>Users>Add>Usersetup.

Note

Max2AXIS9188NetworkI/ORelayModulescanbeconguredwitheachAxisNetworkDoorController

1.Inthedoorcontroller’swebpage,gotoSetup>HardwareCongurationandclickStartnewhardwareconguration.

2.EnteranamefortheAxisproduct.

3.Inthelistofperipherals,selectElevatorcontroltoincludeanAXISA9188NetworkI/ORelayModuleandclickNext.

4.Enteranamefortheconnectedreader.

5.SelectthereaderprotocolthatwillbeusedandclickFinish.

6.ClickNetworkPeripheralstocompletethecongurationseeHowtoaddandsetupnetworkperipheralsonpage16or

clickthelinktogotothehardwarepinchart.
