10 USER MANUAL
1. Take all contents out of a package: the moisture analyser and packed separately: the
tin pan shield, single use pans, the pan handle and the pan support. It is recommended
to keep the original scale package in order to transport the moisture analyzer safely in
future.
2. Place the moisture analyzer on a stable ground not affected by mechanical vibrations
and airflows.
3. Level the moisture analyzer with rotating legs 9 so that the air bubble in water-level 10
at the back of the moisture analyzer is in the middle and the moisture analyser rests
on all four legs.
4. Open the drying chamber 3 by lifting it by a grip at the front. Insert the window 13 into
chamber cover, edges of the window should be located in the latch grooves 14 (push
the window until You hear a “click” from all four latches).
5. Put drying chamber floor board 12 on four position pegs in moisture analyzer cover.
Put covering plate 4 on three distance pegs 8. Put carefully pan mandrel 5 into scale
mechanism hole.
6. Put on empty single-use pan 7 on grip 6 and using the grip place the single pan on
scale’s carrying pan (grip ring 6 will be located inside the plate but due to longer
diameter it will not rest on carrying pan 5).
7. Close the moisture analyzer chamber 3 and connect the scale to 230V supply.
8. This will start moisture analyzer autotests and after stabilization zero indication will
show up. Moisture analyzer will start initial heating signalled by a proper communicate
on the screen. After initial heating moisture analyzer is ready to work.
