AXIS M3114-VE Network Camera
Technical Specifications
Function/group
Item
Specifications
Application
Programming
Interface
Open API for software integration, i n cluding VAPIX® and AXIS Camera Application
Platform from Axis Communications; specifications available at www.axis.com
Includes the ONVIF specification available a t www.onvif.org
Support for AXIS V ideo Hosting System (AVHS) with One-Click Camera Connection
Intelligent video
Video motion detection, active tampering alarm, Support for AXIS Camera Application
Platform enab ling installation of additional appli c ations
Triggers Intelligent video, manual trigger, PTZ preset, PTZ moving, network lost, storage status,
system initializing
Actions File uploa d via FTP, HTTP, and email
Notification via email, HTTP and TCP
Video recording to edge storage
Pre- and post-alarm video buffering
PTZ preset
Guard tour
Status LED
Video access from
web browser
Camera live view
Video recording to file (ASF)
Customizable HTML pages
Windows 7, Windows Vista, Windows XP, Windows Server 2008, Windows Server 2003
DirectX 9c or higher
For other operating systems and browsers, see www.axis.com/techsup
Management and
maintenance
AXIS Camera Management tool on CD and web-based configuration
Firmware upgrades over HTTP or FTP , firmware available on www.axis.com
System
Integration
Installation aids Pixel counter
Casing
IP66-, IP67- and NEMA 4X-rated, IK08 impact-resistant aluminum and p olycarbonate
casing; dehumidifying membrane; captive screws
AXIS M3114-VE: with weather shield
AXIS M3114-VE Noca p/Nocap 2 m m: without weather shield
Processor,
memory
ARTPEC-3, 128 MB RAM , 128 MB Flash
Power
Power over Ethernet (PoE) IEEE 802.3af, max. 3.2 W, PoE Class 1
Connectors
Male RJ-45 10BASE-T/100BASE-TX PoE on a 3 m (9.8 ft.) network cable
Edge storage
Support for recording to
network share (Network Attached Storage or file server).
Operating
conditions
Temperature: -20 ºC to 50 ºC (-4 ºF to 122 ºF)
Humidity 15 - 100% RH (condensing)
Approva
ls
EN 55022 Class B , EN 60950-22, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN
61000-6-2, EN 55024, ICES-003 Class B, FCC Part 15 Subpart B Class B, VCCI Class B
C-tick AS/NZS CISPR 22, EN 60950-1
IEC 60721-3-4 Class 4K3 (temperature range -20°C to 50°C)
IEC 60529 IP66/IP67, NEMA 250 Type 4X
IEC 62262 Class IK08
Dimensions
(HxWxD)
51 x 109 x 107 mm (2.0” x 4.3” x 4.2”) with weather shield
36 x 109 x 107 mm (1.4” x 4.3” x 4.2”) without weather shield
Weight
0.3 kg (0.7 lb.)
General
Included
accessories
Lens tool, top cover tool, drill hole template, m ounting adapter, Installation Guide, CD
with installation tools, recording software and User Manual, Windows decoder 1-user
license
