Axis M3114-VE - Hardware Overview; LED Indicators

AXIS M3114-VE Network Camera
Hardware overview
Caution
Due to local regulations or the environmental a nd electrical conditions in which the p roduct is to be used, a shielde d
network cable (STP) may be appropriate or required. A ny network cab les that are routed in outdoor environments or similar
shall be shielded (STP) and intended for their specific use. Make sure that the network switch is properly grounded . See
Electromagnetic Compatibility (EMC) for regulatory requirements.
Control button - The control button is used for:
• ConnectingtoanAXISVideoHostingSystemservice.Seepage 34. To connect, press and hold the button for about
1 second until the Status LED flashes g reen.
• ConnectingtoAXISInternetDynamicDNSService. Seepage 35. To connect, press and hold the button for
about 3 seconds.
• Resetting the prod uct to factory default settings. See page 40.
LED indicators
LED
Color
Indication
Green
Steady for connection to a 100 MBit/s network. Flashes for network activity.
Amber
Steady for connection to a 10 MBit/s network. Flashes for network activity.
Network
Unlit No network connection.
Green Steady green for normal operation.
Amber
Steady during startup and when restoring settings.
Status
Red
Slow flash for failed upgrade.
Green
Normal operation.
Power
Amber
Flashes green/amber during firmware upgrade.
Note
• The Status LED can be configured to be unlit during normal operation. To configure, g o to Setup > System Options >LED.
See the online help for more inform
ation.
• The Status LED can be configured to flash while an event is active.
• The S tatus LED can be configured to flash for identifying the unit. This can be done under Setup > System Options >
Maintenance.
5
