AXIS M3114-VE Network Camera
Technical Specifications
Technical Specifications
Function/group
Item
Specifications
Model
AXIS M3114-VE: 1 MP, weather shield, 2.9 mm lens
AXIS M3114-VE Nocap: 1 MP, no weather shie ld, 2.9 mm lens
AXIS M3114-VE Nocap 2 mm: 1 MP, no weather shield , 1 .97 mm lens
Image sensor
Progressive scan RGB CMOS 1/4”
Lens M12 mount, fixed iris, megapixel resolution
AXIS M3114-VE/Nocap: 2.9 mm, F2.0
Horizontal angle of view: 80°
Vertical angle of view: 48°
Diagonal angle of view: 100°
AXIS M3114-VE Nocap 2 mm: 1.97 mm, F3.0
Horizontal angle of view: 105°
Vertical angle of view: 67°
Diagonal angle of view: 122°
Minimum
illumination
AXIS M3114-VE/Nocap:1luxF2.0
AXIS M3114-VE Nocap 2 mm:1luxF3.0
Shutter time
1/24500 s to 1/6 s
Camera
Camera angle
adjustment
AXIS M3114-VE: Pan ± 30°, tilt 0° - 65°, rotation ± 180°
AXIS M3114-VE Nocap/Nocap 2 mm: Pan ± 30°, tilt 0° - 90°, rotation ± 180°
Video
compression
H.264 (MPEG-4 Part 10/AVC, Baseline profile)
Motion JPEG
Resolutions
1280x800 (1 MP/HDTV 720p) to 160x90
1440x900 (1.3 MP) scaled r esolution available via VAPIX®
Frame rate H.264 30 fps in all resolutions
Frame rate
Motion JPEG
30 fps in all resolutions
Video streaming
Multiple, individually configurable streams in H.264 and Motion JPEG
Controllable frame rate and bandwidth
VBR/CBR H.264
Pan/Tilt/Zoom
Digital PTZ, preset positions, guard tour
Video
Image settings
Compression, color, brightne ss, sharpness, contrast, white balance, exposure control,
exposure zones, backlight compensation, fine tuning of behavior at low light
Rotation: 0°, 90°, 180°, 270°
Mirroring of images
Text and im age overlay
Privacy
Corridor Format
Wide dynamic range — dynamic contrast
Security Password protection, IP address filtering, HTTPS encryption*, IEEE 802.1X network a ccess
control*, digest authentication, user access log
*This product includes software developed by the Open SSL Project for use in the Open
SSL Toolkit (www.openssl.org)
Network
Supported
protocols
IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP,
SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP,
DHCP, ARP, SOCKS
*This product includes software developed by the Open SSL Project for use in the Open
SSL Toolkit (www.openssl.org)
