Page 12 AXIS P33/P33-V Network Camera Series Installation Guide
Set the password
To gain access to the product, the password for the default administrator user root must be set. This
is done in the Configure Root Password dialog, which is displayed when the network camera is
accessed for the first time.
To prevent network eavesdropping when setting the root password, this can be done via an
encrypted HTTPS connection, which requires an HTTPS certificate.
To set the password via a standard HTTP connection, enter it in the Configure Root Password
window. To set the password via an encrypted HTTPS connection, follow these steps:
1. Click the Create self-signed certificate button.
2. Provide the requested information and click OK. The certificate is created and the password can
now be set securely. All traffic to and from the network camera is encrypted from this point on.
3. Enter a password and then re-enter to confirm the spelling. Click OK. The password has now
been configured.
4. To log in, enter the user name “root” in the dialog as requested.
Note:
The default administrator user name root cannot be deleted.
5. Enter the password as set above, and click OK. If the password is lost, the network camera must
be reset to the factory default settings. See page 21.
If required, click Yes to install AMC (AXIS Media Control), which allows viewing of the video stream
in Internet Explorer. You will need administrator rights on the computer to do this.
Note:
To install AMC in Windows 7/Windows Vista, you must run Internet Explorer as administrator.
Right-click the Internet Explorer icon and select Run as administrator.
To configure the password directly via an
unencrypted connection, enter the
password here.
To create an HTTPS connection, start by
clicking this button.

Other manuals for Axis P3346

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Axis P3346 and is the answer not in the manual?

Axis P3346 Specifications

General IconGeneral
Total megapixels3 MP
Maximum resolution2048 x 1536 pixels
Supported video modes1080p
Video formats supportedH.264, M-JPEG, MPEG4
Supported graphics resolutions2048 x 1536 (QXGA)
Pan range0 - 360 °
White balanceAuto
Tilt angle range0 - 160 °
Angle of rotation340 °
Camera shutter speed1/35500 - 1/6 s
Minimum illumination0.08 lx
Sensor typeCMOS
Optical sensor size1/3 \
Security algorithms802.1x RADIUS, HTTPS
Video motion detectionYes
Audio formats supportedAAC
Cabling technology10/100Base-T(X)
Supported network protocolsIPv4/v6, HTTP, HTTPS, QoS L3, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Dimensions (WxDxH)96 x 148 x 101 mm
Compliance industry standardsIEEE 802.3u, IEEE 802.3af
Power source typePoE
CertificationEN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, EN 60950-1
Processor modelARTPEC-3
Placement supportedIndoor
Flash memory128 MB
Compatible memory cardsSD, SDHC
Housing materialPolycarbonate (PC)
Operating temperature (T-T)0 - 50 °C
Operating relative humidity (H-H)15 - 85 %
Weight and Dimensions IconWeight and Dimensions
Weight490 g
