Axis P3346 Installation Guide

Page 6 AXIS P33/P33-V Network Camera Series Installation Guide
Hardware overview
Dimension (HxW)
AXIS P3346 = 101 x 148 mm (4” x 5.83”)
AXIS P3346-V = 104 x 148 mm (4.07” x 5.83”)
AXIS P3367-V = 104 x 148 mm (4.07” x 5.83”)
AXIS P3384-V = 104 x 148 mm (4.07” x 5.83”)
Weight
AXIS P3346 = 490 g (1.1 lb)
AXIS P3346-V = 700 g (1.53 lb)
AXIS P3367-V = 700 g (1.53 lb)
AXIS P3384-V = 700 g (1.53 lb)
Network connector
LED indicators
Control button
I/O connector
(PoE)
Camera unit
Network cable
Dome cover
out
Audio
in
SD memory card slot
Wall screws
Audio
Camera unit
Fan output
connector
Built-in microphone

Axis P3346 Specifications

General

Total megapixels	3 MP
Maximum resolution	2048 x 1536 pixels
Supported video modes	1080p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	2048 x 1536 (QXGA)
Pan range	0 - 360 °
White balance	Auto
Tilt angle range	0 - 160 °
Angle of rotation	340 °
Camera shutter speed	1/35500 - 1/6 s
Minimum illumination	0.08 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Security algorithms	802.1x RADIUS, HTTPS
Video motion detection	Yes
Audio formats supported	AAC
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS L3, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Dimensions (WxDxH)	96 x 148 x 101 mm
Compliance industry standards	IEEE 802.3u, IEEE 802.3af
Power source type	PoE
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, EN 61000-6-1, EN 61000-6-2, FCC 15 B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, EN 60950-1
Processor model	ARTPEC-3
Placement supported	Indoor
Flash memory	128 MB
Compatible memory cards	SD, SDHC
Housing material	Polycarbonate (PC)
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	15 - 85 %

Weight and Dimensions

Weight	490 g
