Axis P3364-LVE - Mounting Bracket; Led Indicators

AXISP3364-LVENetworkCamera
10
SDmemorycardslot
11
Mountingbracket
12
Unitcasing
13
Spring
14
Fanoutputconnector
15
Domecover
16
Bottomholes
17
Sideholes
MountingBracket
Themountingbrackethas4mountingpatterns(A,B,C,D).
Themountingpatternsfollowthestandardforthefollowingmountingoptions:
•A:4inchsquarebox
•B:standard-sizedUSdoublegangjunctionbox
•C:4inchoctagonbox
•D:standard-sizedUSsinglegangjunctionbox
LEDIndicators
Note
•TheStatusLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,go
toSetup>SystemOptions>Ports&Devices>LED.Seetheonlinehelpformore
information.
•TheStatusLEDcanbeconguredtoashwhileaneventisactive.
•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>System
Options>Maintenance.
