AXISP33/-VSeriesFixedDomeNetworkCamera
Connecteuraudio
Connecteurs
audio3,5mm(stéréo)
123
1Pointe2Anneau3Manchon
Entréeaudio
Entréemicro/ligne
Masse
Sortieaudio
Sortieligne(mono)
Masse
Schémasdeconnexion
Connecteurd'E/S
1
2
3
4
1
0VCC(-)
2
SortieCC3,3V,maxi.50mA
3
Entréenumérique0àmax.40VCC
4
Entréenumérique0àmax.40VCC,drainouvert,max.100mA
