Axis Q1635 - Replace the Lens

AXISQ1635FixedNetworkCamera
HardwareOverview
•Whenthecameraisnotlevel,theLEDsashacombinationofred,greenandorange,andthebeepoccursatslowintervals.
BothLEDsbrieyashgreentoindicatethatthelevellingisgettingbetter.
ReplacetheLens
ItispossibletouseoptionallensesfortheAxisproduct.
Toreplacethelens:
1.Disconnecttheiriscable.
2.Unscrewthestandardlens.
3.Attachandscrewonthenewlens.
Tochangetheirisconguration:
1.GotoSetup>VideoandAudio>CameraSettings.Iriscongurationshowsthecurrentcongurediristype.
2.ClickEdit.
3.Selecttheinstalledirislensfromthedrop-downlistandclickOK.
TochangetheiriscongurationforP-irislensesnotlistedinthedrop-downlist:
1.Downloadtheiriscongurationlefromwww.axis.com
2.GotoSetup>VideoandAudio>CameraSettings.Iriscongurationshowsthecurrentcongurediristype.
3.InIrisconguration:ClickEdit.
4.GototheUploadtab.
5.ClickBrowseandselectthecongurationle.
6.ClickUpload.TheinstalledirislensshouldnowbeincludedintheIrisSelectiondrop-downlist.
7.Selecttheinstalledirislensfromthedrop-downlistandclickOK.
Note
•IfyouselectaDCiriscongurationleforaP-irislens,anerrormessagewillappearbelowtheiriscongurationtypeinthe
CameraSettingspage.ForcustomDCIrislenses,selectGenericDCIrisoption.
•Thereisnoneedtorestarttheproductafterchangingthelens.However,theproductmustberestartedifyouare
interchangingbetweenaP-iris,DC-Irisorxed/manualirislens.Inordertosetthefocusandpositionthelens,the
productmustbeconnectedtothenetwork.
10
