AXISQ1635FixedNetworkCamera

SystemOptions

Ports&Devices

I/OPorts

TheAxisproductprovidestwocongurableinputandoutputportsforconnectionofexternaldevices.Forinformationabout

howtoconnectexternaldevices,seeConnectorsonpage76.

ToconguretheI/Oports,gotoSystemOptions>Ports&Devices>I/OPorts.Eachportcanfunctionasinputoroutput:

•InputasOpencircuit–Theinputbecomesactivewhenthecircuitisgroundedby,forexample,aREXdevice.Itremains

inactiveaslongasitsnormalstateequalsitscurrentstatus.

•InputasGroundedcircuit–Theinputbecomesactivewhenthecircuitisopenedbyforexampleamonitor.

•OutputasOpencircuit–Theoutputportisinanon-conductivestatewhenitscurrentstatusisopencircuit.Thecurrent

statusofanoutputportcanbechangedby,forexample,anactionrule.

•OutputasGroundedcircuit–Theoutputportisinaconductivestatewhenitscurrentstatusisgroundedcircuit.

COMPort

TheAxisproducthasoneRS-485/RS-422serialport.Theportsupportsthefollowingmodes:

•GenericHTTPallowstheAxisproducttoreceivedataandsendcommandsviaHTTP.

•PanTiltZoomisusedtocontrolaPTZdevice.ThePTZdevicerequiresadriver.SeeInstallPTZDriverformoreinformation.

Driverscanbedownloadedfromwww.axis.com

•GenericTCP/IPallowstheAxisproducttoreceivedataandsendcommandsviaTCP/IP.

SelectthedesiredPortTypefromthedrop-downlist.Formoreinformation,seetheonlinehelp

PortStatus

ThelistontheSystemOptions>Ports&Devices>PortStatuspageshowsthestatusoftheproduct’sinputandoutputports.

Accelerometer

Tiltangleindicatestheangletowhichthecamera’slensholderistilted.A0°tiltiswhenthecameraispointingtotheground.It’s

possibletohaveatiltanglebetween0and180°.Totiltto180°,tilttoanangleof90°,rotatethelensholderandtilttoafurther90°.

Rotationangleindicatestheangletowhichthecamera’slensholderisrotated.Therotationrangeisbetween0to360°.Thecamera

isconsideredtobeinalevelpositionwhentherotationangleis0°,90°,360°or270°.

Thelevelingassistantthathelpstolevelthecameraisenabledbydefault.Todisableit,de-selecttheEnablelevelingassistantoption

fromSystemOptions>Ports&Devices>AccelerometerandclickSave.Torefreshthepageandviewthesavedsetting,clickReset.

Maintenance

TheAxisproductprovidesseveralmaintenancefunctions.TheseareavailableunderSystemOptions>Maintenance.

ClickRestarttoperformacorrectrestartiftheAxisproductisnotbehavingasexpected.Thiswillnotaffectanyofthecurrent

settings.

Note

ArestartclearsallentriesintheServerReport.

ClickRestoretoresetmostsettingstothefactorydefaultvalues.Thefollowingsettingsarenotaffected:

•thebootprotocol(DHCPorstatic)
