AXISQ1635FixedNetworkCamera
SetUptheProduct
SetUptheProduct
TheAxisproductcanbeconguredbyuserswithadministratororoperatorrights.Toopentheproduct’sSetuppages,clickSetupin
thetopright-handcorneroftheLiveViewpage.
•Administratorshaveunrestrictedaccesstoallsettings.
•Operatorshaverestrictedaccesstosettings,seeUsersonpage55
Seealsotheonlinehelp
.
BasicSetup
BasicSetupprovidesshortcutstothesettingsthatshouldbemadebeforeusingtheAxisproduct:
1.Users.Seepage55.
2.TCP/IP.Seepage58.
3.Date&Time.Seepage57.
4.VideoStream.Seepage21.
5.Focus.Seepage30
6.AudioSettings.Seepage30.
TheBasicSetupmenucanbedisabledfromSystemOptions>Security>Users.
AdjustFocus
Toadjustthezoomandfocusfollowtheseinstructions:
Note
•SetfocusaspreciselyaspossiblewiththefocusringorFocusAssistantbeforestartingautomaticnetuning.Using
thefocusringnormallygivesthebestresult.
•Theirisshouldalwaysbeopenedtoitsmaximumwhilefocusing.Thisgivesthesmallestdepthofeldandthusthe
bestconditionsforcorrectfocusing.
1.Opentheproduct’shomepageandgotoSetup>BasicSetup>Focus.
2.UndertheBasictab,clickOpeniris.Ifthebuttonisinactivetheirisisalreadyopen.
3.Iffocushasbeensetbefore,clickResettoresetthebackfocus.
4.Loosenthezoompullerandthelockscrewforthefocusring(seeHardwareOverviewonpage6)onthelensbyturning
themcounter-clockwise.Movethezoompullerandthefocusringtosetzoomandfocusandcheckthequalityof
theimageintheimagewindow.
5.Re-tightenthezoompullerandthelockscrewforthefocusring.
6.OntheFocuspage,clickFine-tunefocusautomaticallyandwaituntilautomaticnetuningiscompleted.
7.ClickEnableiris.Ifthebuttonisinactivetheirisisalreadyenabled.
8.Ifneeded,makefurtheradjustmentsundertheAdvancedtab.Seetheonlinehelpformoreinformation.
19
