Axis Q1635 User Manual

AXISQ1635FixedNetworkCamera
TechnicalSpecifications
Function/group
Item
Specications
Optional
accessories
AXIST8414InstallationDisplay
AXISPoweroverEthernetMidspan1-port
AXISCameraStationandvideomanagementsoftwarefromAxis’Application
DevelopmentPartners
Languages
German,French,Spanish,Italian,Russian,SimpliedChinese,Japanese,Korean,
Portuguese
Warranty
Axis3-yearwarrantyandAXISExtendedWarrantyoption,seewww.axis.com/warranty
Connectors
I/OConnector
4–pinterminalblock
1
2 3 4
Foranexamplediagram,seeConnectionDiagramsonpage77.
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
12VDC
Maxload=50mA
Digitalinput–Connecttopin1toactivate,orleaveoating
(unconnected)todeactivate.
0tomax30VDC Congurable
(InputorOutput)
3–4
Digitaloutput–Connectedtopin1whenactivated,oating
(unconnected)whendeactivated.Ifusedwithaninductive
load,e.g.arelay,adiodemustbeconnectedinparallelwith
theload,forprotectionagainstvoltagetransients.
0tomax30VDC,opendrain,
100mA
PowerConnector
2-pinterminalblockforDCpowerinput.UseaSafetyExtraLowVoltage(SELV)compliant
limitedpowersource(LPS)witheitheraratedoutputpowerlimitedto≤100Woraratedoutput
currentlimitedto≤5A.
AudioConnector
3.5mmaudioconnectors
(stereo)
123
76
