AXISQ1635FixedNetworkCamera

HardwareOverview

AudioConnector

TheAxisproducthasthefollowingaudioconnectors:

•Audioin(pink)–3.5mminputforamonomicrophone,oraline-inmonosignal.

•Audioout(green)–3.5mmoutputforaudio(linelevel)thatcanbeconnectedtoapublicaddress(PA)systemoran

activespeakerwithabuilt-inamplier.Astereoconnectormustbeusedforaudioout.

RS485/RS422Connector

TwoterminalblocksforRS485/RS422serialinterfaceusedtocontrolauxiliaryequipmentsuchaspan-tiltdevices.

SDCardSlot

NO NO

TICE TICE

TICE

•RiskofdamagetoSDcard.DonotusesharptoolsorexcessiveforcewheninsertingorremovingtheSDcard.

•Riskofdataloss.Topreventdatacorruption,theSDcardshouldbeunmountedbeforeremoval.Tounmount,gotoSetup>

SystemOptions>Storage>SDCardandclickUnmount.

ThisproductsupportsmicroSD/microSDHC/microSDXCcards(notincluded).

ForSDcardrecommendations,seewww.axis.com

ControlButton

Forlocationofthecontrolbutton,seeHardwareOverviewonpage6.

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.Seepage68.

•ConnectingtoanAXISVideoHostingSystemservice.Seepage59.Toconnect,pressandholdthebuttonforabout3

secondsuntiltheStatusLEDashesgreen.

•ConnectingtoAXISInternetDynamicDNSService.Seepage59.Toconnect,pressandholdthebuttonforabout3seconds.

FunctionButton

Thefunctionbuttonhasmultiplefunctions:

•Levellingassistant–Thisfunctionhelpstoensurethecameraislevel.Pressthebuttonforabout3secondstostartthe

levellingassistantandpressagaintostopthelevelingassistant.ThestatusLEDandbuzzersignalassistlevellingofthe

camera,seeStatusLEDBehaviorandBuzzerSignalforLevellingAssistantonpage9.Thecameraislevelwhenthe

buzzerbeepscontinuously.

•Focusassistant–ThisfunctionisusedforenablingtheFocusAssistant.Toenablethefocusassistant,pressandvery

quicklyreleasethebutton.Pressagaintostopthefocusassistant.Formoreinformation,seetheInstallationGuide.

LEDIndicators

Note

•TheStatusLEDcanbeconguredtobeunlitduringnormaloperation.Tocongure,gotoSetup>SystemOptions>Ports

&Devices>LED.Seetheonlinehelpformoreinformation.

•TheStatusLEDcanbeconguredtoashwhileaneventisactive.

•TheStatusLEDcanbeconguredtoashforidentifyingtheunit.GotoSetup>SystemOptions>Maintenance.
