AXIS Q19 Series Installation Guide Page 7
ENGLISH
AXIS Q1910-E/Q1921-E/Q1922-E
Sunshield adjustment
Sunshield
Top cover
Thermal network camera
Bottom cover
Cable cover
Bottom cover screws (4x)
Cable cover screws (4x)
Cable holes with
Safety wire tab
Protective window with
Network cable (route
Wall bracket
Bracket adjustment screw
through wall bracket)
Bracket adapter
screw (2x)
Bracket adapter
Example image: AXIS Q1910-E
Part number (P/N) & Serial number (S/N).
The serial number may be required
during the installation.
De-humidifying membrane
Do not remove!
cable glands (3x)
screws (4x)
Wall bracket
Thermal Network Camera and Housing
window heater cabe (premounted)
