MACHINE ILLUSTRATION OF THE MILL
Main tool post
Tilt housing
0-45˚ tilt
Typ. 4
bolts
Rear View
Tilt
scale
Rise & fall
drive screw
27
Rise & fall drive screw handle
Angle support casting
