2a. SCREW CUTTING
For selection of the required thread pich please refer to the chart on the gear train cover, select
the correct gears from the change wheel set and mount them in the correct sequence.
(See fig 1 & 1a)
A
B
C
D
Fig 1
Fig 1a
GEAR CHART
