Azbil HLS Series User Manual

10-7
Part name Actuator model Stem size Material Part No. Qty.
Main packing
HA3 φ13 mm
P4519 80255385-111 5
Belleville spring SUS304 82559308-101 4
O-ring (small) Viton 82592221-497 1
O-ring (large) Viton 82592222-297 1
Stem connector S20C/S25C 82571706-011 1
Gland stud SUS304 82571706-011 2
Gland nut SUS304 82592448-173 2
Spring case SUS304 82559309-101 1
Packing follower SUS304 82571712-101 1
Packing follower for O-ring use SUS304 82571716-101 1
Spacer SUS304 82555645-166 1
Spacer for O-ring use SUS304 82555645-666 1
Main packing
HA3 φ16 mm
P4519 80255386-111 5
Belleville spring SUS304 82559308-102 4
O-ring (small) Viton 82592221-797 1
O-ring (large) Viton 82592222-897 1
Stem connector S20C/S25C 82521091-201 1
Gland stud SUS304 82559312-011 2
Gland nut SUS304 82592448-013 2
Spring case SUS304 82559310-101 1
Packing follower SUS304 82571713-101 1
Packing follower for O-ring use SUS304 82571717-101 1
Spacer SUS304 82555645-766 1
Spacer for O-ring use SUS304 82555645-101 1
Main packing
HA4 φ20 mm
P4519 80255387-111 5
Belleville spring SUS304 82571710-201 4
O-ring (small) Viton 82592221-997 1
O-ring (large) Viton 82592223-397 1
Stem connector S20C/S25C 82551348-202 1
Gland stud SUS304 82571707-011 2
Gland nut SUS304 82592448-023 2
Spring case SUS304 82571709-101 1
Packing follower SUS304 82571714-101 1
Packing follower for O-ring use SUS304 82571718-101 1
Spacer SUS304 82555645-866 1
Spacer for O-ring use SUS304 82555645-201 1
