9-4
9-2. Model HTS control valves
9-2-1. Structures
The structure of model HTS Control Valve is shown in Figure 9-3.
Figure 9-3 Model HTS Control Valve
Hex Nut (2)
Bellows Flange
Backup Ring
Seal Ring
Stem
Bellows Seat
Bell
ows Assembly
Gasket (4)
Extension Bonnet
Gasket (1)
Guide Ring
Gasket (2)
Hex
Nut (1)
P
acking Flange Nut
Packing Flange
Gasket (3)
Valve plug
Pin
Valve Body
Hex Nut (3)
