11-5. Parts List
Table 11-6. Parts list for PTFE yarn
Part name Actuator model Material Part No. Qty.
Main packing
HA2
P4519 80255384- 111 3
Adapter packing P6720 82573475- 101 2
Carbon ring P6210C2FS 82573484- 001 2
Belleville spring SUS304 82573462- 101 6
O-ring (small) Viton 82592220- 897 1
O-ring (large) Viton 82592221- 897 1
Gland stud A193 GrB8CL2 82559311- 012 2
Gland nut SUS304 82592448- 163 2
Packing flange SCS13 82573456- 101 1
Packing follower SUS304 82573463- 101 1
Packing follower for
O-ring use
SUS304 82573464- 101 1
Spacer SUS304 82573476- 110 1
Main packing
HA3
(except 6B)
P4519 80255385- 111 3
Adapter packing P6720 82573475- 102 2
Carbon ring P6210C2FS 82573484- 002 2
Belleville spring SUS304 82573462- 102 6
O-ring (small) Viton 82592221- 497 1
O-ring (large) Viton 82592222- 297 1
Gland stud A193 GrB8CL2 82571706- 012 2
Gland nut SUS304 82592448- 173 2
Packing flange SCS13 82573457- 101 1
Packing follower SUS304 82573465- 101 1
Packing follower for
O-ring use
SUS304 82573466- 101 1
Spacer SUS304 82573476- 111 1
Stem connector S25C/S20C 82571732- 101 1
Main packing
HA3
(6B)
P4519 80255386- 111 3
Adapter packing P6720 82573475- 103 2
Carbon ring P6210C2FS 82573484- 003 2
Belleville spring SUS304 82573462- 103 6
O-ring (small) Viton 82592221- 797 1
O-ring (large) Viton 82592222- 897 1
Gland stud A193 GrB8CL2 82559312- 012 2
Gland nut SUS304 82592448- 013 2
Packing flange SCS13 82573458- 101 1
Packing follower SUS304 82573467- 101 1
Packing follower for
O-ring use
SUS304 82573468- 101 1
Spacer SUS304 82573476- 112 1
