User Manual
Page 20 of 40
Step 3
Press the Simple Connect Button for two seconds on the existing HomePlugAV
device. After you release the button, the Power LED will continuously blink. If the
Power LED did not blink, press the Simple Connect again for two seconds.
Make sure to press the Simple Connect Button again on the HomePlugAV X within
two minutes after you press the Simple Connect from the existing network.
Step 4
To confirm if the connection was established, check the LEDs. The Power LEDs and
the Powerline Activity LEDs on all HomePlugs are on.
If the Powerline Activity LED on HomePlug X is OFF, this means the pairing was
unsuccessful. You have to repeat steps 1 to 3 again until all LEDS in all HomePlugAV
devices are on .
