AzureWave AW-GA800BT User Manual

4
-
2
General Specifications
Model Name
AW-GA800BT
Product Description
USB Wireless Module
WLAN Standard
IEEE 802.11b/g, Wi-Fi compliant
Host Interface
USB 2.0
Dimension
35mm x 80mm x 11.7mm
(not including SMA connector and pin headers)
Weight
15 g
Operating Conditions
Voltage
3.3V +/- 5%
Temperature
Operating: 0 ~ 55
o
C; Storage: -20 ~ 65
o
C
Humidity
15% ~ 95%
Electrical Specifications
Frequency Range
2.4 GHz ISM radio band
Number of Channels
802.11b: USA, Canada and Taiwan – 11 (2412~2462MHz)
Most European Countries – 13, France – 4, Japan – 14
802.11g: USA, Canada and Taiwan– 11 (2412~2462MHz)
Most European Countries – 13, Japan – 14
Modulation
802.11b: CCK(11, 5.5Mbps), DQPSK(2Mbps), BPSK(1Mbps)
802.11g: OFDM
Output Power
802.11b: typical 17 dBm (Peak Power 22.63 dBm)
802.11g: typical 14 dBm (Peak Power 22.64 dBm)
Antenna
SMA connector for external antenna
Receive Sensitivity
802.11b: typical -86dBm at 11Mbps
802.11g: typical -68dBm at 54Mbps
Data Rates
802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
Power Consumption
802.11b: TX:500mA; RX:315mA at 3.3V
