Operating Manual
BL2 93317
14
5.3 RC suppressor unit
6 Commissioning
6.1 Factory default settings
The values printed in bold are the factory settings.
6.2 Self-test cycle
After power-on, the detector goes through a self-test cycle of 10 s. Different flashing of the LEDs
(see chapter 3.3 "LED indicators") indicates whether the detector has already been programmed or
whether the factory settings are active.
NOTICE
Interference suppression of the loads!
All switched loads must be properly suppressed.
We recommend our RC suppressor units (see accessories).
Device
Switch-on threshold
500 Lux
Adjustment range by remote control:
20 Lux - 1000 Lux
Sensitivity
High
(HIGH, MEDIUM, LOW)
Status LEDs
Function active
(active, inactive)
Follow-up time
3 min
(15 s – 60 min)
INFO
With a switch-on threshold greater than 1000 lux (day mode, "sun" setting), the light
evaluation is inactive, i.e. the detector operates independently of brightness.
