Operating Manual
BL2 93317
16
6.3.2 Parameter
Button Parameter
Day operation
The switching of the output when a movement is detected is almost light-independent
(switch-on threshold approx. 2000 lux).
Night operation
The light evaluation is performed with a minimum switch-on threshold of 10 lux.
to
Switch-on threshold
The brightness value below which the illumination is switched on is called the switch-
on threshold.
The switch-on threshold can be selected between 20 Lux and 1000 Lux. Below this
value, the illumination is switched on during movement.
to
Follow-up time
This is the duration after a movement for which the connected illumination remains
switched on.
or
o
r
Detection sensitivity
With a high detection sensitivity, even smaller movements are detected and larger
areas are detected.
Status LEDs
This button is used to activate or deactivate the status LEDs.
