General Description

Nr. Picture Name Description

HVA Power Supply Plug Mains plug (power supply) on HVA

HVA28 USB USB Port inside vent grasp

HVA Communication Serial connection between PC&HVA (side panel)

PD Power Supply Plug Mains plug (power supply) PD-2 CC/ PD30-E

PD-2 CC/PD30-E

Communication

Plug for communication cable between PD-2CC / PD30-E and PC

via USB cable

PD Battery Battery compartment PDTD-2

HVA-USB Connection PC-USB connection between HVA

b2 Dongle-USB Connection PC-USB Dongle (Software dongle)

PD-USB Connection PC-USB connection between PC&PD

PC-Bluetooth Communication PC-USB Bluetooth Dongle
