B2 HVA28 - Appropriate Applications and Operator Qualifications

Safety
© b2 electronic GmbHDHV0086 Rev0610
2�3 Appropriate Applications
The HVA testing instruments is designed to perform high voltage insulation
testing of various types of highly capacitive loads.
Appropriate DUTs
DUT Type Examples
Cables • Extruded cables (e.g. XLPE)
• Laminated cables (e.g. PILC)
• Insulated cables
• Cable jackets/sheaths
Other highly capacitive loads • Generators
• Switchgear
• Transformers
• Rotating machines
• Insulators
• Bushings
Appropriate measurements
Measurement Examples
Test • Capacitance
• Resistance
• Dielectric breakdown voltage
• RMS current
• Applied voltage
NOTICE
Other Applications
Before proceeding, contact b2 to validate appropriate use!
2�4 
HVAoperatorsmustbequaliedelectricaltechnicians!Proofofnecessary
qualicationsforworkinginhighvoltagedomain ismandatory.It ishighly
recommended that operators have completed an emergency rescue training
programme.
