B2 HVA28 - Operation Modes: Test and Output Modes

Design and Construction
© b2 electronic GmbHDHV0086 Rev0632
4�4 Operation Modes
Described below are the various HVA operation modes.
Test Modes, Output Modes (Waveform), Arc Management Modes, and Data
Transfer Modes.
Test Modes
The HVA can be operated in manual or automatic mode. For detailed procedure,
see 5.2 Manual Test Mode on page 40, and see 5.3 Automatic Test Mode
on page 55.
Test mode Characteristics
Manual Designed to facilitate rapid testing. Test parameters of the last manual
test appear as the default settings.
• Test parameters can be changed before activating a test.
• Test types: VLF, VLF TD, DC, ST, SFL, VB
Automatic Designedfortestingwithapredenedcongurationinordertosatisfy
specicrequirements(e.g.IEEEorIECstandards).
• Thetestsequencemustbeconguredandsavedbeforetesting.
• Test types: VLF, VLF TD, DC, ST, VB
