B2 HVA28 - Page 17

General Description
© b2 electronic GmbH DHV0086 Rev06 17
Art� Nr� Item Image pcs Art� Nr� Item Image pcs
VS0002 HVA28 shoulder strap
for Peli Case
1 KEK0126 Connection Lead
External Guard 4 mm
- Snap
2
KEK0127 Test Lead 4 mm 1,5 m
Black MFK15-1-150
1 KES0021 Dolphin Clip 32 A 4 mm
Jack Red
2
KMD0081 Corona Shield Two-
Part, Min. Clearance
Distance = 10 mm
2 KMSO0064 HVA Guard connection
DUT
2
HVA34-1 / HVA45 Accessories
The following items are included in the HVA34-1 and HVA45 delieveries.
Art� Nr� Item Image pcs Art� Nr� Item Image pcs
GH0661
2
HVA45 HV Test Lead
100 kV TD 5 m MC14
1 VK0060 HVA34-1/ HVA45 card
board
585 x 383 x 700 mm
1
VKR0045 HVA45 Lap top bag for
accessories
1
HVA34TD-1 / HVA45TD Accessories
The following items are included in the HVA34TD-1 and HVA45TD delieveries.
Art� Nr� Item Image pcs Art� Nr� Item Image pcs
GH0661
2
HVA45/TD HV cable
100 kV/5 m/MC14 mm
1 VK0060 HVA34-1/ HVA45 card
board
585 x 383 x 700 mm
1
VKR0045 HVA45 Lap top bag for
accessories
1 KEK0126 Connection Lead
External Guard 4 mm
- Snap
2
KEK0127 Test Lead 4 mm 1,5 m
Black MFK15-1-150
1 KES0021 Dolphin Clip 32 A 4 mm
Jack Red
2
KMD0081 Corona Shield Two-
Part, Min. Clearance
Distance = 10 mm
2
KMSO0064 HVA Guard connection
DUT
2
2
The HV cable GH0661 is not PD free. For measuremts in combination with a PD system you need a PD-free cable.
